ROADTEC RP-195 HIGHWAY CLASS ASPHALT PAVER
OVERVIEW
THE RP-195 IS A POWERFUL, RUBBER-TRACK PAVER MADE FOR HIGHWAY WORK.
The RP-195 features a fully oscillating track frame to provide a smooth ride and lay a smoother mat. The RP-195 is also equipped with our exclusive anti-segregation design of the feed tunnel, discharge, and rear augers. The heavy-duty frame, solid front axle, and sturdy conveyors are engineered for durability. Seats of the dual operator stations can move hydraulically out beyond the sides of the machine to give the operator an excellent view down the sides of the machine.

SPECIFICATIONS
Engine Specifications
Engine MFG CumminsModel QSB 6.7Max Power 230 hp @ 1,900 rpmNumber of Cylinders 6Electrical 24

Weight & Dimensions Specifications
Shipping Length (Tractor Only) 16' 8Shipping Length with Rear Mount Screed 18' 4Shipping Width 10' 6Shipping Height 9' 11Tractor Operating Width 10' 6Deck Height 6' 1Wheelbase 10' 2Inside Turning Radius 4' 6Weight (Tractor Only) 39,220 lbs

Capacities Specifications
Hydraulic Tank Capacity 76 galFuel Tank Capacity 100 galCooling System 9 galDEF 5 gal

Drive Specifications
Final Drive 2 speedNumber of Drive Pumps 2Number of Drive Motors 2Paving Speed 0-284 fpmTravel Speed 0-7.5 mphGround Clearance 7Steering Steering WheelControls Movement Hydraulic SwingSuspension Rubber TireFront Bogies Balanced

Feed System Specifications
Hopper Capacity 13.8 ton/252 ft3Hopper Width 10' 3Feed Control Sonic and Flow GatesAuger Diameter 16Distance Between Augers and Back Wall 1.5Minimum Auger Height 2Hydraulic Tunnel Extensions Optional
