DYNAPAC F1800C
Basic paving width: 70.87 in
Max. paving width: 185.04 in
Max. layer thickn.: 7.87 in
Theor placement cap.: 350 t/h
Masses
Paver weight (incl. standard screed) 23,100 lbsTractionMaximum paving speed 295,280 fpmTransport speed 218.72 fpm
Engine
Manufacturer/Model Deutz, 2,9L TD 4 CylinderRated power 55.4 kW @ 2200 rpmEmissions according to Eu Stage VElectrical system 24 VFuel tank capacity 22 galDEF tank capacity galAlternative EngineManufacturer/Model Deutz, 2,9L TD 4 CylinderRated power 54 kW @ 2200 rpmRated power, SAE J1995 Emissions according to Eu Stage IIIAElectrical system 24 VFuel tank capacity 22.46 galDEF tank capacity galAlternative EngineManufacturer/Model OperationOperational controls ConventionalPlatform Extendable roof, slidable seat station, sliding/tilting control panel, swivel seat
Conveyor
Conveyor control Automatic with paddlesConveyor type Dual bar feederConveyor width 27.56 in
OPERATIONS & MAINTENANCE MANUALS+
SALES ARGUMENTS+
Simplified user interfaceRobust & compact designPerfect visibility with slidable seatsHigh efficiency drive trainPerfect traction
SPARE PARTS MANUALS+
COMPACTION DATA+
LEVEL IIPlease Log in or Register to MyDynapac to get access.
