8616D Asphalt Pavers
The 8616D Asphalt Paver encompasses many features of a larger highway-class paver yet maintains a sleek footprint to better suit the commercial contractor looking for a heavier unit. Highly adaptable for heavy commercial jobs, the flexible spontaneous design gives the operator the ability to switch the unit from high deck to low deck in the matter of minutes. There's nothing left to desire as this unit provides greater serviceability with easy to locate components, consistent material flow and the Legend HD PRO Screed for higher production yields.

Technical Specifications
Operator's Controls
High deck/low deck configurationIncludes dual electronic steerDual, independent adjustable control stations interchangeable in the fieldDash panel includes augers, screed extension, cut-offs, screed, hopper wings, conveyors, grade controls, steering and lightsUser-friendly, icon-based CAN Bus controlsBacklit keypad with LED indicator lightsColored LED, sunlight viewable control screen with digital readouts. Review and monitor system vitals including: RPM, paving speeds, system pressures, screed temperature and generator usage

Dimensions
Length: 16' 4'Width: 8' 6 transport10' hopper wings downHeight: 6' 8 low deck7' 10 high deckTotal Weight (with screed): 23,450 lbs

Engine
Kubota turbocharged dieselTier 4 Final - 127 HP (95 kW)Remote mounted DOC + DPF + SCRMURR I/O distributor blocks with LED lighting

Capacities
Fuel: 37 gallonsHydraulic: 31 gallonsWashdown tank: 7 gallonsDEF tank: 5 gallons
